O.D. 3-3/8", Thread Type 2-13/16"-6Acme-2G, Bottom Sub for Perforating Guns
Material
This bottom sub is built with top-grade alloy steel that has been chosen based on higher strength and wear-resisting properties. The steel goes through rigorous heat treatment that enhances the hardness of the steel and the life of the part against abusive downhole environments. The rugged and hard material resists the part weakening and compromising strength and operation during abusive pressures of the perforating operation.
Specifications
• Outer Diameter (O.D.): 3-3/8 inches
• Thread Type: 2-13/16"-6Acme-2G
• Material: Heat-treated steel with higher strength and higher resistance against corrosion
• Pressure Rating: Engineered to withstand high-pressure environments
• Customizable Length: Available in a variety of lengths suitable for specific perforating gun needs
• Weight: Optimized in the balance of strength and ease of installation
|
Sub O.D. |
Thread Type |
Pressure Rating |
Approx. Weight |
|
3-3/8" |
2-13/16"-6Acme-2G |
25,000 psi [172Mpa] |
14.3lb [6.5kg] |
Production Processes
The O.D. 3-3/8" Bottom Sub has been made with a set of careful processes that help it be of the highest standards of quality:
1. Forging: The manufacturing starts with the forging of good-quality alloy steel into the original shape with a good strength of the structure.
2. CNC Machining: The sub is machined with the help of sophisticated CNC machines that conform to strict dimensional standards to fit perfectly with the rest of the perforating tools.
3. Thread Cutting: The 2-13/16"-6Acme-2G threading is correctly cut into the part with the rest of the perforating gun fragments.
4. Heat Treatment: The lower sub subsequently receives a heat treatment after machining in order to enhance hardness and fatigue strength required within the abusive perforating environment.
5. Surface Finishing: The sub receives a final surface fining treatment of removing any deficiencies and smoothing it and making it rugged.
